How To Fill A Fountain Pen: A Step-By-Step Guide

Step-By-Step Guide: How To Fill Your Fountain Pen (All Pen Types)

We’ve all seen them, and many of us enjoy them on the daily, but the question we are asked most often is: how do you even use a fountain pen?

With so many different options on the market today, it can be overwhelming if you’re a beginning pen-thusiast that wishes to get your hands a little inky. Where would I even begin?

Well, the first step in taking the plunge is to determine which filling method your pen uses.

Determining The Filling Mechanism Of Your Pen

Determine The Filling Mechanism

If you’re looking at a fountain pen and don’t know where to begin, it’s naturally easiest to ask the sales representative what filling mechanism your pen uses.

But, if you’re shy like me and don’t feel like asking, you can tinker around and find out quite easily on your own.

Start by placing one hand on the barrel, and the other hand on the grip section, just above the nib. Gently twist to see if the piece comes apart.

If these two pieces do not come apart, this likely means that your pen has a built-in filling mechanism. If they do twist apart, go ahead and take apart the pen. Make sure none of the guts fall out when you’re doing this.

Once inside, you may see nothing at all! This is a sign that your pen uses either cartridges, or a piston converter.

It may also have a piston converter installed already, which means that you can use ink from a bottle. The other, less common option that we have seen is called a squeeze converter. See the images below to determine which option you see when unscrewing your pen.

Once you have determined which method your pen uses, just click the below links and jump straight to find how to fill your pen:


Built-in Filling Mechanism

Piston fillers

These are a bit complicated to manufacture, so they are typically seen on more valuable fountain pens, such as a Montblancs or Montegrappas.

They involve internal mechanisms that can suck ink straight into the pen, typically by turning the piston knob on the back, or butt-end of the pen. To start, fully untwist the piston. If it shatters, you’ve twisted too far! Just kidding, this definitely shouldn’t happen - stopping at the resistance point is recommended.

FIlling a Piston Converter With Ink

Then, simply insert the nib into a bottle of ink, and twist the piston the opposite direction. This draws that precious liquid gold inside the internal reservoir by retracting the piston, which also seals it from leaking. You can wear that white dress shirt with confidence now!

Refilling Piston Converter With Take-Sumi Ink

After you have filled your pen, you may want to dab it on a cloth to remove the excess ink on the nib, unless you enjoy getting a little messy. Now it’s time to write!


Vacuum fillers

Used by brands such as Visconti on their top of the line Homo Sapiens, and Opera models.

They are highly complex to produce, but are pretty darn fun to use! To start, twist the knob at the end of the pen out completely. You’ll feel that the knob is loose once it has been completely untwisted.

 Vacuum Filled Fountain Pen

It may be a little tight, but now you can pull the knob towards you. This pulls the plunger up the barrel, which creates a low-pressure environment inside the chamber of the pen.

Insert the nib into an ink bottle, and now push the knob all the way back in. It’s important to allow 5-10 seconds for the chamber to fully fill with ink.

How to Refill Vacuum Filled Fountain Pen

Then you can twist the knob back into place, and your fancy new pen is ready to manifest your visions!

Vacuum Filled - Insert the nib into an ink bottle, and now push the knob all the way back in


Crescent filler

Used on some Conklin pens. It consists of a crescent-shaped metal piece that must be pushed inside of the barrel.

It’s kind of awkward at first, but super easy once you figure it out. There is usually a plastic piece that goes underneath the crescent.

You can twist this piece around until the opening lines up with the crescent, which allows it to be pressed into the barrel. This piece prevents you from accidentally discharging ink in your pocket.

Crescent Filled Conklin Pen

When depressed, this collapses the ink sac inside the pen. Then, simply insert the nib into your favorite ink bottle, and let the crescent piece go and the pen fills with ink.

Crescent Filled: Once The Ink Sac Is Depressed Insert Pen Into The Ink

The crescent can also act as a roll stopper for that crooked desk in your office!


Cartridges and Converters

Cartridge Filled

If your pen is cartridge filled, you have the easiest job of them all!
Simply unscrew the grip section from the barrel of the pen. If you look inside the grip section, there is a small piece that protrudes.Cartridge Filled Fountain Pen
The job of this piece is to puncture the cartridge so that ink goes directly into the feed of the pen, allowing for quick and easy writing.
The main downside to cartridges is that many manufacturers use proprietary cartridges that don’t work with all pens, so your selection of ink colors is quite limited.
You can get around this, on most pens, by installing a converter!
Ah, the freedom…now you can use whatever magic potion you want!
Push Cartridge Into The Pen's Puncturing Mechanism To Refill It's Ink

Piston Converter Filled

The quickest and easiest way to use ink from the bottle, a converter filled fountain pen has the same installation technique as a cartridge filled pen.
You must first push the converter into the grip section. Then you should twist the top of the converter so that the internal plunger reaches the bottom.How to Refill a piston converter fountain pen
Insert the converter into a bottle of ink, and twist the plunger back to the top. Then, re-install the barrel to the pen, and you're ready to go!
Now you can use black ink, blue ink, pink ink, yellow ink, blood, Windex, whatever you want! (just kidding, please don’t use Windex)
Twist The Piston Converter To Suck Ink Into The Ink Container

Squeeze Converter Filled

If your pen has a squeeze converter already installed, simply push in the button on the side, insert the nib into an ink bottle, and release the button.
How to Refill a Squeeze Converter
You will want to release the button slowly in order to get the maximum amount of ink to suction into the converter.

push in the button on the side, insert the nib into an ink bottle, and release


 Cartridges vs. Converters

So why would I choose to use a cartridge over a converter? There are a few reasons. Some converters require long stems that you must twist in order to move the plunger inside.

This means that it only holds enough ink to fill the bottom portion of the unit. With a cartridge, the entire unit is filled with ink, which means that you sometimes have double the amount of ink in a cartridge that you would have in a converter. If you’re a nerd like me, though, you’ll probably want a converter, even though it holds less ink. Hey, you can trade out ink colors more often this way!


Built-in vs Hand Installed Mechanisms

Some fountain pen lovers prefer built-in mechanisms due to the fact that they hold such a large quantity of ink. This means that you won’t have to keep refilling your pen all the time if you are a heavy writer. The downside is that these pens tend to be a bit more expensive, and they cannot be used with ink cartridges, so you have to spend that Starbucks money on bottled ink.

Here are a few of our favorite pens from all fill types!

1. Piston fillers:
Montblanc 149 – an all time classic, the Montblanc 149 is a must for any serious collector.
- Montegrappa Monte-Grappa – good enough to be named twice, so that’s good enough for me.
Aurora Optima – refined, elegant pen with a little Italian flair.
2. Vacuum fillers:
Visconti Opera Master Stardust - time for a shameless plug for the Truphae exclusive.
Visconti Opera Master Corvina - our second exclusive design.
3. Crescent fillers:
- Conklin Mark Twain – well, it’s the only one we know of.
4. Cartridge/Converter fillers:
LAMY Safari or Al-Star – a reliable workhorse for every day use at a reasonable price.
Visconti Breeze – gorgeous Italian designs, and available in brilliantly vibrant colors.
Esterbrook Estie – my personal favorite design from 2018!
JINHAO Silver Dragon – Beautifully designed dragon theme for only $29.50.
